My goal is to edit the edge shape of this doublet of the form on the left into the one on the rightHello eveyone, I have a doublet lens seen on the picture seen above, I want to transform the edge shape of my lens (on the left) to the one as seen on the right. I shared the lens .zmx file below in .zip format.  Any help is appreciated.Best regards

HelloI have to simulate a NSC component and some image analysis in non-sequential mode.Kindly help on how to use paraxial surfaces in NSC mode and how to set up the parameters (focal length, exit pupil location etc.) Thanks

Hi I want to export the lens design I drew on Zemax to Solidworks. I've never had a problem with my version in 2019 before. But now, when I save it as stl or step file(in fact, it creates a file type in the form of '.stl.log' and then I delete the' log ' part.) using the CAD Files tool and open it through solidworks, nothing appears.

Hello, I am using OpticStudio21.2.1 and its NSV Shaded model viewer takes enormous time (~20min) to finish update. Showing objects are 6 rectangular detectors, 9 source points, 45 layout rays.Once the updated is settled, I rock the update but the initial update (or every time I changed object coordinates) it goes to update and takes ~20min to finish the update and it is a pain.Anybody knows what is going on and how to solve this? RegardsKazu

Dear all. I would like to simulate bent fiber bundle beam divergence which include almost 8,000 single mode fiber. but I am wondering if it is reasonable to model a bundle of fibers by inputting 8,000 single fibers. Also, for analysis, after dividing the fiber front modeling(objective lens part) and the fiber rear modeling(condensing lens part), is there any problem if the wavelength distribution incident on the fiber front part is applied to the source of the fiber rear modeling? Thank you

Hi Everyone!My name is Jordan Teich and I am working from Boston as an Optical Engineer on the Zemax Customer Success team.  I only just joined the team in early 2021, but I’ve had a great experience here so far! Before joining Zemax, I received my B.S. in Optical Engineering at the University of Rochester.  After graduating, I worked as an Optical Test Engineer in the aerospace industry for ~4.5 years.  It was a fast-paced environment where I was able to run optical tests for a number of interesting space payloads and sub-assemblies! I loved getting the chance to work with cutting edge space products.Besides working, I love spending time outside playing tennis, hiking any nearby mountains, or exploring new areas on my bike.  You will also often find me watching older movies that are playing at one of the repertory theatres in the Boston area.  Looking forward to talking with you all on the new forums!

Hello,I am currently trying to implement 3D-Printed optical lenses (plastic) into my system in sequential mode.However, I am experiencing issues when it comes to insert a new material. I know that to really implement a new material the wavelength dependend dispersion formula is needed. However, I only have a constant refractive index given.Could someone tell me if there is the possibility to implement a material without any thermal or wavelength dependencies? Thank you very much in advance!

Hi,The "Y angle" interval is 0.8 (degrees), as shown in the figure below.But I want to get the data "Y angle" interval is 0.1 (degree).The maximum field keeps 80.0 degrees. How can I get the data "Y angle" interval is 0.1 (degree)?Thank you! Anna

Can someone share macro for tolerancing focal length? The tolerancing menu does not contain it.

Can someone point me to a model using a VIPA (Virtually Imaged Phase Array)?  I keep getting tangled up in transitions from pupil to line focus to image, and I think someone must have figured out a better way.  For reference, https://lightmachinery.com/optics/custom-optics/vipas/.Thanks,Eric MentzellNASA Goddard Optics

Hi, I am a student trying to improve light uniformity for a hydroponic system. Which layout would be optimal, square, rectangle etc. Also, how do I determine the distance between each LED. Are there are any optical structures (i.e  Fresnel Lens/Collimator) there are simplified so I can make to improve light uniformity?Thanks, appreciate your help.

Greetings, I am creating a horicultural fixture. Which data do I collect to convert it into PPFD. For instance, do I collect the luminous intensity or incoherent illumination. Also, is there a simple mathematical factor that relate the data I mentioned to PPFD so that conversion can be done quickly?Thanks!

My name is Kats Ikeda, and I am the Regional Customer Success Manager for the APAC region for the Zemax Customer Success Division. I’ve been with Zemax for a little over two years, initially as Principal Optical Engineer. Before joining Zemax, I worked for a plastic lens manufacturing company and designed a vast array of optical systems, such as cell phone lenses, automotive headlamps, backlight displays, HMD prisms, micro lens diffusers, laser scanning units, and telecommunication lenses. So, safe to say you can ask me about a lot of things. In my spare time, I made a website about optical design. I write about the basics of optical design, not so much how to use software.https://www.pencilofrays.com/blog/Yes, even my hobby involves optics and lens design, so I have been bit by the optics bug pretty hard. It must have been radioactive.Apart from optics, I have a young family in Japan. I love to prepare food for my children, and love it even more when they enjoy it.

Hi Community! Allow me to introduce myself.My name is Flurin Herren, and I am the Optomechanical Engineer for the European CS Team here at Zemax. I have a degree in Microtechnology and Medical Technology with a specialisation in Optics and Photonics where I mostly worked in the field of Optical Coherence Tomography and one in Mechanical Engineering where I specialised in CAD, CAM, and prototype manufacturing.Outside work you`ll probably find me on a trip with my Triumph bike, hiking somewhere in the beautiful Alpes or running / cycling through the city to meet some friends.Feel free to reach out to me anytime, but you will only get the super bonus digital high-five if you reach out to me about OptitcsBuilder  .

I need an annular source with collimated output. In other words, it would be like a ‘source ellipse’ using the source distance. Except, all the rays coming from the annulus would be collimated at a single angle, either converging or diverging. Any ideas on how to accomplish this? Thanks

I’d like to go ahead and introduce myself briefly. I joined Zemax in January of 2019 as an Optical Engineer working on OpticStudio support. Prior to that I have worked for Boeing and for the European Southern Observatory headquarters as well as some other educational forays into the intellectual worlds of sciences and humanities. My educational background is primarily from Rensselaer Polytechnic Institute and the University of New Mexico, heavily emphasizing optical physics.Besides work, I enjoy various RPGs and board games, reading about history, and watching too much Star Wars and Star Trek.

All the information below is obsolete. Please refer to this knowledge base article for full information. Introduction to Enhanced Ray Aiming and Ray Aiming Wizard Q: What is this?Starting from 21.1, we have added experimental feature for the Ray-Aiming algorithm, which are supposed to solve Ray-Aiming problems in some extreme user cases or novel application designs. In these challenging cases, the current Ray-Aiming algorithm usually has hard time to find the chief ray that hitting STOP center for the problematic field.Since the new algorithm is still in beta testing, it’s not enabled by default. Users need to explicitly turn on the feature in order to test the new function.Q: What problems does the experimental feature solve?A system with Ray-Aiming problems can end up in many different syndromes. The following are a few examples. Note it’s important to know the following error could be caused by other reasons but not Ray-Aiming. It could be the system has reached the physical limitat

Hi guys, I’d like to use this post to introduce myself! I’m with the Zemax Customer Success team and help our customers with their technical inquiries on our software. I’ve been with the team for 3 and half years now and am loving every part of the job! I got my PhD in Physical from U of R and before joining Zemax I worked at GigOptix Inc for about 10 years on developing high speed electro optic polymer modulators. I love working with lasers!I hope to see everyone here often in the new forum and let’s chat OpticStudio! :)

Probably 1.5 years ago I submitted a bug report for Zemax to fix a bug where the filename would be cutoff at the first dot/period in the filename. For example, saving a plot as 'def=1.35_xxx.png' will only save a file as 'def=1.png' Come on, it's not that hard to fix!

Can I model and optimise a sequential cylindrical surface somehow? Or is it just a non-sequential option as they are obviously not rotationally symmetric.

I creat Michelson interferometer by using non-sequential mode, there is no fringes in the detector(the yellow one), the fringe exsit in reference mirror plane(the right side last plane), I do not know what is wrong?

Hello, Is there a method or tool to save a .bmp file as a .IMA file?  I have a bitmap of a target reticle I created in Solidworks and I want to perform an extended diffraction analysis.  The extended diffraction analysis requires an IMA file. Thanks, Pat

Dear sir/madam,I opened a zemax file, while opneing it is showing a error that “ Coating THOR os not defined in Coating file”. But the same file i opened in the morning it was working properly.  Now this time Coating Error is coming, I tried to retify it but couldn’t. Can help me? I have attached the Screenshot for your reference.

Dear Madam, Sir, we use OpticStudio with License in a black USB key. I have just downloaded and updated the newest release. But I am asked for the code several times in a row and Opticstudio will not open. I assume that our current license code and the key don’t match the Opticstudio release. I would like therefore if it is possible to require a new License code which match this release. Unless I will reinstall the old version that we use. Could you please tell us with which version we can return back? We need to use OpticStudio urgently, please help us to resolve this issue as quickly as possible. Best regards,

Clients open up Zemax, I open of the gemelto website and the product are not there. I configure the clients to point to the license server but the client is still displaying. How do I get the client to switch to the license server via the website.
